18R254C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 250UH 800MA 255 MOHM
- CategoryFixed Inductors
- Datasheet 18R254C Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$1.29
- 100$1.29
Quote It
Technical Details
- Series:1800R
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:250 µH
- Tolerance:±10%
- Current Rating (Amps):800 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):255mOhm Max
- Q @ Freq:40 @ 100kHz
- Frequency - Self Resonant:3.85MHz
- Ratings:-
- Operating Temperature:0°C ~ 70°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:Radial Lead
- Size / Dimension:0.539" Dia (13.70mm)
- Height - Seated (Max):0.626" (15.90mm)
