PG0083.401NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 400NH 17.5A 3.2 MOHM
- CategoryFixed Inductors
- Datasheet PG0083.401NLT Datasheet
-
ECAD Model
- Share
In Stock: 115
Can ship immediately
Pricing:
- 1$1.302
- 2,000$1.302
Quote It
Technical Details
- Series:PG0083
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:400 nH
- Tolerance:±25%
- Current Rating (Amps):17.5 A
- Current - Saturation (Isat):27A
- Shielding:Unshielded
- DC Resistance (DCR):3.2mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 95°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.268" L x 0.268" W (6.80mm x 6.80mm)
- Height - Seated (Max):0.165" (4.20mm)
