4232-822J

Technical Details

• Series:4232
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Iron
• Inductance:8.2 µH
• Tolerance:±5%
• Current Rating (Amps):263 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):3Ohm Max

• Q @ Freq:30 @ 7.9MHz
• Frequency - Self Resonant:21MHz
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:7.9 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:2-SMD
• Supplier Device Package:-
• Size / Dimension:0.138" L x 0.105" W (3.51mm x 2.67mm)
• Height - Seated (Max):0.101" (2.57mm)
