784383340056
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560NH 3.6A 34.8 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$1.411
- 1,000$1.411
Quote It
Technical Details
- Series:WE-MAIA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:Iron Alloy
- Inductance:560 nH
- Tolerance:±30%
- Current Rating (Amps):3.6 A
- Current - Saturation (Isat):8.5A
- Shielding:Shielded
- DC Resistance (DCR):34.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:108MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1212 (3030 Metric)
- Supplier Device Package:3012
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.047" (1.20mm)
