CDEP134NP-6R0MC-H
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6UH 6.5A 18.4 MOHM SMD
- CategoryFixed Inductors
- Datasheet CDEP134NP-6R0MC-H Datasheet
-
ECAD Model
- Share
In Stock: 170
Can ship immediately
Pricing:
- 1$1.428
- 500$1.428
Quote It
Technical Details
- Series:CDEP134
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6 µH
- Tolerance:±20%
- Current Rating (Amps):6.5 A
- Current - Saturation (Isat):9.6A
- Shielding:Shielded
- DC Resistance (DCR):18.4mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.531" L x 0.531" W (13.50mm x 13.50mm)
- Height - Seated (Max):0.197" (5.00mm)
