CLF12555T-331M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 330UH 700MA 672 MOHM
- CategoryFixed Inductors
- Datasheet CLF12555T-331M Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$1.45
- 500$0.702
- 1,000$0.624
- 2,500$0.6045
- 5,000$0.585
- 12,500$0.5655
Quote It
Technical Details
- Series:CLF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:330 µH
- Tolerance:±20%
- Current Rating (Amps):700 mA
- Current - Saturation (Isat):1.2A
- Shielding:Shielded
- DC Resistance (DCR):672mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.476" W (12.50mm x 12.10mm)
- Height - Seated (Max):0.230" (5.85mm)
