P3519R-152J

Technical Details

• Series:P3519R
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1.5 µH
• Tolerance:±5%
• Current Rating (Amps):2.71 A
• Current - Saturation (Isat):3.53A
• Shielding:Unshielded
• DC Resistance (DCR):40mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-55°C ~ 130°C
• Inductance Frequency - Test:10 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.358" L x 0.190" W (9.09mm x 4.83mm)
• Height - Seated (Max):0.185" (4.70mm)
