33681C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 920MA 183 MOHM
- CategoryFixed Inductors
- Datasheet 33681C Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$1.67
- 40$1.67
Quote It
Technical Details
- Series:3300
- Package:Tray
- Part Status:Active
- Type:Toroidal
- Material - Core:-
- Inductance:680 µH
- Tolerance:±15%
- Current Rating (Amps):920 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):183mOhm Max
- Q @ Freq:0.64 @ 800kHz
- Frequency - Self Resonant:900kHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:800 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical, 4 Leads (Open)
- Supplier Device Package:-
- Size / Dimension:1.142" L x 0.642" W (29.00mm x 16.30mm)
- Height - Seated (Max):1.220" (31.00mm)
