15684C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 1.12A 574 MOHM
- CategoryFixed Inductors
- Datasheet 15684C Datasheet
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
- 1$1.68
- 40$1.68
Quote It
Technical Details
- Series:1500
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:680 µH
- Tolerance:±10%
- Current Rating (Amps):1.12 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):574mOhm Max
- Q @ Freq:86 @ 25kHz
- Frequency - Self Resonant:1MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.661" Dia (16.80mm)
- Height - Seated (Max):0.839" (21.30mm)
