4922R-30K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 270UH 470MA 1.77 OHM
- CategoryFixed Inductors
- Datasheet 4922R-30K Datasheet
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$2.49496
- 800$2.22317
Quote It
Technical Details
- Series:4922R
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:270 µH
- Tolerance:±10%
- Current Rating (Amps):470 mA
- Current - Saturation (Isat):470mA
- Shielding:Unshielded
- DC Resistance (DCR):1.77Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD
- Supplier Device Package:-
- Size / Dimension:0.520" L x 0.250" W (13.21mm x 6.35mm)
- Height - Seated (Max):0.230" (5.84mm)
