1331R-564K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 40MA 28 OHM SMD
- CategoryFixed Inductors
- Datasheet 1331R-564K Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$2.448
- 500$2.1488
Quote It
Technical Details
- Series:1331R
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±10%
- Current Rating (Amps):40 mA
- Current - Saturation (Isat):12mA
- Shielding:Shielded
- DC Resistance (DCR):28Ohm Max
- Q @ Freq:35 @ 790kHz
- Frequency - Self Resonant:7MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:790 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD
- Supplier Device Package:-
- Size / Dimension:0.313" L x 0.115" W (7.95mm x 2.92mm)
- Height - Seated (Max):0.145" (3.68mm)
