P1812R-563H
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 240MA 2.268 OHM
- CategoryFixed Inductors
- Datasheet P1812R-563H Datasheet
-
ECAD Model
- Share
In Stock: 103
Can ship immediately
Pricing:
- 1$2.5704
- 650$2.25624
Quote It
Technical Details
- Series:P1812R
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±3%
- Current Rating (Amps):240 mA
- Current - Saturation (Isat):336mA
- Shielding:Unshielded
- DC Resistance (DCR):2.268Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.189" L x 0.134" W (4.80mm x 3.40mm)
- Height - Seated (Max):0.134" (3.40mm)
