2500R-16G
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 104MA 12.3 OHM
- CategoryFixed Inductors
- Datasheet 2500R-16G Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$2.5715
- 2,500$2.1452
Quote It
Technical Details
- Series:2500R
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Molded
- Material - Core:Iron
- Inductance:560 µH
- Tolerance:±2%
- Current Rating (Amps):104 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):12.3Ohm Max
- Q @ Freq:65 @ 790kHz
- Frequency - Self Resonant:3.6MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:790 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.240" Dia x 0.740" L (6.10mm x 18.80mm)
- Height - Seated (Max):-
