PA2247.822NLT
PulseLarsen Antenna- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 8.2UH 25A 7.2MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$2.46451
Quote It
Technical Details
- Series:PA2247.XXXNLT
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:8.2 µH
- Tolerance:±20%
- Current Rating (Amps):25 A
- Current - Saturation (Isat):28A
- Shielding:Unshielded
- DC Resistance (DCR):7.2mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.650" L x 0.610" W (16.50mm x 15.50mm)
- Height - Seated (Max):0.394" (10.00mm)
