4922-43L
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3MH 126MA 25 OHM SMD
- CategoryFixed Inductors
- Datasheet 4922-43L Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$2.50945
- 800$2.50945
Quote It
Technical Details
- Series:4922
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 mH
- Tolerance:±15%
- Current Rating (Amps):126 mA
- Current - Saturation (Isat):126mA
- Shielding:Unshielded
- DC Resistance (DCR):25Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.505" L x 0.240" W (12.82mm x 6.09mm)
- Height - Seated (Max):0.230" (5.84mm)
