PTHF500-894H
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 500UH 3.4A 131 MOHM TH
- CategoryFixed Inductors
- Datasheet PTHF500-894H Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$14.63
- 100$12.6536
Quote It
Technical Details
- Series:PTHF
- Package:Bulk
- Part Status:Active
- Type:Toroidal
- Material - Core:Molybdenum Permalloy(MPP)
- Inductance:500 µH
- Tolerance:±10%
- Current Rating (Amps):3.4 A
- Current - Saturation (Isat):3.1A
- Shielding:Shielded
- DC Resistance (DCR):131mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:800kHz
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal (Open)
- Supplier Device Package:-
- Size / Dimension:1.300" Dia (33.02mm)
- Height - Seated (Max):0.650" (16.51mm)
