PTHF750R-59VM
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 750UH 2.1A 240 MOHM TH
- CategoryFixed Inductors
- Datasheet PTHF750R-59VM Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
- 1$19.398
- 100$16.7766
Quote It
Technical Details
- Series:PTHFR-VM
- Package:Bulk
- Part Status:Active
- Type:Toroidal
- Material - Core:Molybdenum Permalloy(MPP)
- Inductance:750 µH
- Tolerance:±10%
- Current Rating (Amps):2.1 A
- Current - Saturation (Isat):1.8A
- Shielding:Shielded
- DC Resistance (DCR):240mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:500kHz
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical (Open)
- Supplier Device Package:-
- Size / Dimension:1.210" L x 0.685" W (30.73mm x 17.40mm)
- Height - Seated (Max):1.250" (31.75mm)
