3500-10K
API Delevan
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 120UH 169MA 4.7 OHM TH
- CategoryFixed Inductors
- Datasheet 3500-10K Datasheet
-
ECAD Model
- Share
In Stock: 176
Can ship immediately
Pricing:
- 1$22.3789
- 100$19.35416
Quote It
Technical Details
- Series:3500
- Package:Bulk
- Part Status:Active
- Type:-
- Material - Core:Iron
- Inductance:120 µH
- Tolerance:±10%
- Current Rating (Amps):169 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):4.7Ohm
- Q @ Freq:75 @ 790kHz
- Frequency - Self Resonant:9.3MHz
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:790 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.250" Dia x 0.560" W (6.35mm x 14.22mm)
- Height - Seated (Max):-
