70F102AI
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10MH 38MA 101 OHM TH
- CategoryFixed Inductors
- Datasheet 70F102AI Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:70F
- Package:Bulk
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Iron
- Inductance:10 mH
- Tolerance:±5%
- Current Rating (Amps):38 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):101Ohm Max
- Q @ Freq:41 @ 250kHz
- Frequency - Self Resonant:520kHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:250 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.330" Dia x 0.380" L (8.38mm x 9.65mm)
- Height - Seated (Max):-
