8230-86
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 560UH 48MA 46 OHM TH
- CategoryFixed Inductors
- Datasheet 8230-86 Datasheet
-
ECAD Model
- Share
In Stock: 126
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:8230
- Package:Bulk
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:560 µH
- Tolerance:±10%
- Current Rating (Amps):48 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):46Ohm Max
- Q @ Freq:30 @ 790kHz
- Frequency - Self Resonant:5MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:790 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.120" Dia x 0.300" L (3.05mm x 7.62mm)
- Height - Seated (Max):-
