78FR33K

Technical Details

• Series:78F
• Package:Bulk
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:330 nH
• Tolerance:±10%
• Current Rating (Amps):815 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):80mOhm Max

• Q @ Freq:40 @ 25MHz
• Frequency - Self Resonant:350MHz
• Ratings:-
• Operating Temperature:-55°C ~ 105°C
• Inductance Frequency - Test:25 MHz
• Features:-
• Mounting Type:Through Hole
• Package / Case:Axial
• Supplier Device Package:-
• Size / Dimension:0.110" Dia x 0.280" L (2.79mm x 7.11mm)
• Height - Seated (Max):-
