78F120J
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 12UH 155MA 800 MOHM TH
- CategoryFixed Inductors
- Datasheet 78F120J Datasheet
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:78F
- Package:Bulk
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:12 µH
- Tolerance:±5%
- Current Rating (Amps):155 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):800mOhm Max
- Q @ Freq:45 @ 2.5MHz
- Frequency - Self Resonant:20MHz
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:2.5 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.110" Dia x 0.280" L (2.79mm x 7.11mm)
- Height - Seated (Max):-
