PM40-271K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 270UH 92MA 18 OHM SMD
- CategoryFixed Inductors
- Datasheet PM40-271K Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PM40
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Molded
- Material - Core:Ferrite
- Inductance:270 µH
- Tolerance:±10%
- Current Rating (Amps):92 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):18Ohm Max
- Q @ Freq:30 @ 796kHz
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:796 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1812 (4532 Metric)
- Supplier Device Package:1812
- Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max):0.126" (3.20mm)
