PM125S-220M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 2.2A 70 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM125S-220M Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PM125S
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):2.2 A
- Current - Saturation (Isat):4.04A
- Shielding:Shielded
- DC Resistance (DCR):70mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:15MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.496" L x 0.457" W (12.60mm x 11.60mm)
- Height - Seated (Max):0.213" (5.40mm)
