2122-H
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 1.4A 330 MOHM TH
- CategoryFixed Inductors
- Datasheet 2122-H Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:2100
- Package:Bulk
- Part Status:Obsolete
- Type:Toroidal
- Material - Core:-
- Inductance:680 µH
- Tolerance:±15%
- Current Rating (Amps):1.4 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):330mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal (Open)
- Supplier Device Package:-
- Size / Dimension:0.860" Dia (21.84mm)
- Height - Seated (Max):0.450" (11.43mm)
