ELJ-PB221KF

Technical Details

• Series:PB
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:-
• Inductance:220 µH
• Tolerance:±10%
• Current Rating (Amps):90 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):9Ohm Max

• Q @ Freq:20 @ 796kHz
• Frequency - Self Resonant:4MHz
• Ratings:-
• Operating Temperature:-20°C ~ 85°C
• Inductance Frequency - Test:796 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1812 (4532 Metric)
• Supplier Device Package:1812
• Size / Dimension:0.177" L x 0.126" W (4.50mm x 3.20mm)
• Height - Seated (Max):0.134" (3.40mm)
