3500-820K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 82UH 330MA 1.2 OHM TH
- CategoryFixed Inductors
- Datasheet 3500-820K Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:3500
- Package:Bulk
- Part Status:Obsolete
- Type:-
- Material - Core:Ferrite
- Inductance:82 µH
- Tolerance:±10%
- Current Rating (Amps):330 mA
- Current - Saturation (Isat):850mA
- Shielding:Unshielded
- DC Resistance (DCR):1.2Ohm Max
- Q @ Freq:53 @ 2.52MHz
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial
- Supplier Device Package:-
- Size / Dimension:0.385" L x 0.150" W (9.78mm x 3.81mm)
- Height - Seated (Max):0.300" (7.62mm)
