PM3316S-470M

Technical Details

• Series:PM3316S
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:47 µH
• Tolerance:±20%
• Current Rating (Amps):800 mA
• Current - Saturation (Isat):1A
• Shielding:Shielded
• DC Resistance (DCR):472mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 85°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.512" L x 0.374" W (13.00mm x 9.50mm)
• Height - Seated (Max):0.201" (5.10mm)
