CR54-220MC

Technical Details

• Series:CR54
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:22 µH
• Tolerance:±20%
• Current Rating (Amps):1.11 A
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):180mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:19.5MHz
• Ratings:-
• Operating Temperature:-30°C ~ 100°C
• Inductance Frequency - Test:2.52 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.228" L x 0.209" W (5.80mm x 5.30mm)
• Height - Seated (Max):0.191" (4.85mm)
