CTX01-16025

Technical Details

• Series:CTX
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Toroidal
• Material - Core:Iron Powder
• Inductance:120 µH
• Tolerance:±25%
• Current Rating (Amps):2 A
• Current - Saturation (Isat):1.7A
• Shielding:Unshielded
• DC Resistance (DCR):62mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 150°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.697" L x 0.506" W (17.70mm x 12.85mm)
• Height - Seated (Max):0.297" (7.55mm)
