SH50T-0.85-680
Amgis
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 850MA 1.25 OHM
- CategoryFixed Inductors
- Datasheet SH50T-0.85-680 Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SH50
- Package:Tray
- Part Status:Obsolete
- Type:Toroidal
- Material - Core:Iron Powder
- Inductance:680 µH
- Tolerance:±20%
- Current Rating (Amps):850 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.25Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:10 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Horizontal - Corner Terminals
- Supplier Device Package:-
- Size / Dimension:0.689" L x 0.669" W (17.50mm x 17.00mm)
- Height - Seated (Max):0.492" (12.50mm)
