ELL-4GG120M
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 12UH 650MA 380 MOHM
- CategoryFixed Inductors
- Datasheet ELL-4GG120M Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:G
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:-
- Inductance:12 µH
- Tolerance:±20%
- Current Rating (Amps):650 mA
- Current - Saturation (Isat):800mA
- Shielding:Shielded
- DC Resistance (DCR):380mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.150" L x 0.150" W (3.80mm x 3.80mm)
- Height - Seated (Max):0.055" (1.40mm)
