ELL-6PG2R2N
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 2.2A 37 MOHM SMD
- CategoryFixed Inductors
- Datasheet ELL-6PG2R2N Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:G
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:-
- Inductance:2.2 µH
- Tolerance:±30%
- Current Rating (Amps):2.2 A
- Current - Saturation (Isat):2.2A
- Shielding:Shielded
- DC Resistance (DCR):37mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.079" (2.00mm)
