CM100505-2N7DL

Technical Details

• Series:CM100505
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Alumina
• Inductance:2.7 nH
• Tolerance:±0.3nH
• Current Rating (Amps):400 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):100mOhm Max

• Q @ Freq:8 @ 100MHz
• Frequency - Self Resonant:5.5GHz
• Ratings:-
• Operating Temperature:-40°C ~ 100°C
• Inductance Frequency - Test:100 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0402 (1005 Metric)
• Supplier Device Package:0402 (1005 Metric)
• Size / Dimension:0.039" L x 0.020" W (1.00mm x 0.50mm)
• Height - Seated (Max):0.024" (0.60mm)
