CPL2512T1R5M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 1A 156 MOHM SMD
- CategoryFixed Inductors
- Datasheet CPL2512T1R5M Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:CPL
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):1.2A
- Shielding:Shielded
- DC Resistance (DCR):156mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.098" L x 0.059" W (2.50mm x 1.50mm)
- Height - Seated (Max):0.047" (1.20mm)
