B82466G152M

Technical Details

• Series:B82466G0
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1.5 µH
• Tolerance:±20%
• Current Rating (Amps):920 mA
• Current - Saturation (Isat):1A
• Shielding:Shielded
• DC Resistance (DCR):145mOhm

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.079" L x 0.079" W (2.00mm x 2.00mm)
• Height - Seated (Max):0.039" (1.00mm)
