SCIHP1367-4R7M

Technical Details

• Series:SCIHP1367
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:-
• Inductance:4.7 µH
• Tolerance:±20%
• Current Rating (Amps):13.5 A
• Current - Saturation (Isat):25A
• Shielding:Shielded
• DC Resistance (DCR):11.2mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:200 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.543" L x 0.508" W (13.80mm x 12.90mm)
• Height - Seated (Max):0.264" (6.70mm)
