SCMD4D12-100

Technical Details

• Series:SCMD4D12
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:-
• Material - Core:-
• Inductance:10 µH
• Tolerance:±20%
• Current Rating (Amps):780 mA
• Current - Saturation (Isat):1.1A
• Shielding:Unshielded
• DC Resistance (DCR):480mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.252" L x 0.197" W (6.40mm x 5.00mm)
• Height - Seated (Max):0.057" (1.45mm)
