SCPS6450-050

Technical Details

• Series:SCPS6450
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:-
• Material - Core:-
• Inductance:50 nH
• Tolerance:±20%
• Current Rating (Amps):30 A
• Current - Saturation (Isat):70A
• Shielding:Shielded
• DC Resistance (DCR):290mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 125°C
• Inductance Frequency - Test:1 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.283" L x 0.264" W (7.20mm x 6.70mm)
• Height - Seated (Max):0.205" (5.20mm)
