AIAC-1008C-68NK-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68NH 380MA 37.1 MOHM
- CategoryFixed Inductors
- Datasheet AIAC-1008C-68NK-T Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:AIAC-1008C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Air
- Inductance:68 nH
- Tolerance:±10%
- Current Rating (Amps):380 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):37.1mOhm Max
- Q @ Freq:70 @ 300MHz
- Frequency - Self Resonant:1.3GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:300 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.126" L x 0.075" W (3.20mm x 1.90mm)
- Height - Seated (Max):0.087" (2.20mm)
