SRP1235-1R0M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 24A 3.5 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRP1235-1R0M Datasheet
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SRP1235
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:-
- Material - Core:Iron
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):24 A
- Current - Saturation (Isat):36A
- Shielding:Shielded
- DC Resistance (DCR):3.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:60MHz
- Ratings:-
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.547" L x 0.531" W (13.90mm x 13.50mm)
- Height - Seated (Max):0.146" (3.70mm)
