CM201212-R68KL

Technical Details

• Series:CM201212
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Polymer
• Inductance:680 nH
• Tolerance:±10%
• Current Rating (Amps):130 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):2.99Ohm Max

• Q @ Freq:10 @ 25.2MHz
• Frequency - Self Resonant:100MHz
• Ratings:-
• Operating Temperature:-40°C ~ 100°C
• Inductance Frequency - Test:25.2 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:0805 (2012 Metric)
• Supplier Device Package:0805 (2012 Metric)
• Size / Dimension:0.079" L x 0.050" W (2.00mm x 1.27mm)
• Height - Seated (Max):0.058" (1.47mm)
