SRE6603-681M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 680UH 180MA 2.2OHM SMD
- CategoryFixed Inductors
- Datasheet SRE6603-681M Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:SRE6603
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:680 µH
- Tolerance:±20%
- Current Rating (Amps):180 mA
- Current - Saturation (Isat):55mA
- Shielding:Shielded
- DC Resistance (DCR):2.2Ohm Max
- Q @ Freq:40 @ 100kHz
- Frequency - Self Resonant:3MHz
- Ratings:-
- Operating Temperature:-25°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.175" W (6.60mm x 4.45mm)
- Height - Seated (Max):0.115" (2.92mm)
