B82442T1185J50

Technical Details

• Series:SIMID
• Package:Tape & Reel (TR)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:1.8 mH
• Tolerance:±5%
• Current Rating (Amps):110 mA
• Current - Saturation (Isat):183mA
• Shielding:Unshielded
• DC Resistance (DCR):19.7Ohm Max

• Q @ Freq:30 @ 252kHz
• Frequency - Self Resonant:1.4MHz
• Ratings:AEC-Q200
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:252 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:2-SMD, J-Lead
• Supplier Device Package:2220 (5650 Metric)
• Size / Dimension:0.220" L x 0.197" W (5.60mm x 5.00mm)
• Height - Seated (Max):0.209" (5.30mm)
