LQH3NPN100NM0L

Technical Details

• Series:LQH3
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:10 µH
• Tolerance:±30%
• Current Rating (Amps):870 mA
• Current - Saturation (Isat):550mA
• Shielding:Shielded
• DC Resistance (DCR):312mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:45MHz
• Ratings:-
• Operating Temperature:-40°C ~ 85°C
• Inductance Frequency - Test:1 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:1212 (3030 Metric)
• Supplier Device Package:1212 (3030 Metric)
• Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
• Height - Seated (Max):0.059" (1.50mm)
