CDR156NP-5R6MC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 5.6UH 7A 13.5 MOHM SMD
- CategoryFixed Inductors
- Datasheet CDR156NP-5R6MC Datasheet
-
ECAD Model
- Share
In Stock: 190
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:CDR156
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:5.6 µH
- Tolerance:±20%
- Current Rating (Amps):7 A
- Current - Saturation (Isat):12.8A
- Shielding:Unshielded
- DC Resistance (DCR):13.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 100°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.728" L x 0.591" W (18.50mm x 15.00mm)
- Height - Seated (Max):0.276" (7.00mm)
