MBH10145C-100MA=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 3.3A 37 MOHM SMD
- CategoryFixed Inductors
- Datasheet MBH10145C-100MA=P3 Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$0.59536
- 500$0.567
- 1,000$0.504
- 2,500$0.48825
- 5,000$0.4725
- 12,500$0.45675
Quote It
Technical Details
- Series:MBH10145C
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):3.3 A
- Current - Saturation (Isat):3.1A
- Shielding:Shielded
- DC Resistance (DCR):37mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.409" L x 0.409" W (10.40mm x 10.40mm)
- Height - Seated (Max):0.189" (4.80mm)
