47681SC

Technical Details

• Series:4700S
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Type:Wirewound
• Material - Core:-
• Inductance:680 µH
• Tolerance:±20%
• Current Rating (Amps):480 mA
• Current - Saturation (Isat):-
• Shielding:Shielded
• DC Resistance (DCR):1.78Ohm Max

• Q @ Freq:17 @ 800kHz
• Frequency - Self Resonant:4MHz
• Ratings:-
• Operating Temperature:-40°C ~ 85°C
• Inductance Frequency - Test:10 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard, 4 Lead
• Supplier Device Package:-
• Size / Dimension:0.480" L x 0.480" W (12.20mm x 12.20mm)
• Height - Seated (Max):0.197" (5.00mm)
