592502B03400G
Aavid
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionHEATSINK TO-220 VERT MNT W/TABS
- CategoryThermal - Heat Sinks
- Datasheet 592502B03400G Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$3.06
- 10$2.907
- 25$2.76164
- 50$2.68898
- 100$2.65263
- 250$2.47096
- 500$2.3256
- 1,000$2.10758
- 5,000$2.0349
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Type:Board Level, Vertical
- Package Cooled:TO-220
- Attachment Method:Bolt On and PC Pin
- Shape:Rectangular, Fins
- Length:1.250" (31.75mm)
- Width:0.874" (22.20mm)
- Diameter:-
- Fin Height:0.250" (6.35mm)
- Power Dissipation @ Temperature Rise:1.0W @ 30°C
- Thermal Resistance @ Forced Air Flow:10.00°C/W @ 200 LFM
- Thermal Resistance @ Natural:22.00°C/W
- Material:Aluminum
- Material Finish:Black Anodized
