UMV1E100MFD
Nichicon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10UF 20% 25V RADIAL
- CategoryAluminum Electrolytic Capacitors
- Datasheet UMV1E100MFD Datasheet
-
ECAD Model
- Share
In Stock: 2,795
Can ship immediately
Pricing:
- 1$0.56
- 10$0.38972
- 100$0.23349
- 500$0.1751
- 1,000$0.14787
- 2,500$0.14009
- 5,000$0.13231
Quote It
Technical Details
- Series:UMV
- Package:Bulk
- Part Status:Active
- Capacitance:10 µF
- Tolerance:±20%
- Voltage - Rated:25 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:23 mA @ 120 Hz
- Ripple Current @ High Frequency:34.5 mA @ 10 kHz
- Impedance:-
- Lead Spacing:0.079" (2.00mm)
- Size / Dimension:0.197" Dia (5.00mm)
- Height - Seated (Max):0.236" (6.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
